Description
HR FR LSH Single Core Cables
These are flexible single-core cables designed for internal wiring in power and control panels, switchgear, relay, and instrumentation panels.
Standard Colors :
01 – Red
02 – Black
03 – Green
04 – Blue
05 – Yellow
06 – Grey
07 – White
INDUSTRIAL CABLES – HR- FR-LSH
SGI SAFE FIRE – HRFRLSH Wires are extensively used by machine tools, electrical appliances, Control Panel and heavy machinery manufactures. These wires provide increased current carrying capacity and have higher resistance to Heat (1050 C) , emit very low smoke and halogen which ensures better visibility and faster evacuation in case of any eventuality.
Heat Resistant – Flame Retardant – Low Smoke (HR-FR-LSH) Single Core PVC Insulated Copper Conductor (Unsheathed) Cable 1100 Voltage Grade Confirming to IS:694.
| Nominal Area of Conductor (Sq.mm) | Product Code | No./Nom. Dia of Cond. Strands (mm) | Nominal Thickness (mm) | Approx. Overall Diameter (mm) | Max. Resistance at 20°C (Ω/km) | Current Carrying Capacity (Amp.) |
|---|---|---|---|---|---|---|
| 0.5 | SW-1301 | 16/0.2 | 0.6 | 2.1 | 39 | 4 |
| 0.75 | SW-1302 | 24/0.2 | 0.6 | 2.3 | 26 | 7 |
| 1 | SW-1303 | 32/0.2 | 0.6 | 2.5 | 19.5 | 12 |
| 1.5 | SW-1304 | 30/0.25 | 0.6 | 2.9 | 13.3 | 16 |
| 2.5 | SW-1305 | 50/0.25 | 0.7 | 3.6 | 7.98 | 22 |
| 4 | SW-1306 | 56/0.3 | 0.8 | 4.1 | 4.95 | 29 |
| 6 | SW-1307 | 84/0.3 | 0.8 | 4.8 | 3.3 | 37 |
| 10 | SW-1308 | 80/0.4 | 1 | 6.1 | 1.91 | 51 |
| 16 | SW-1309 | 126/0.4 | 1 | 7.3 | 1.21 | 68 |
| 25 | SW-1310 | 196/0.4 | 1.2 | 8.7 | 0.78 | 86 |
| 35 | SW-1311 | 276/0.4 | 1.2 | 10.3 | 0.554 | 110 |
| 50 | SW-1312 | 396/0.4 | 1.4 | 12.4 | 0.386 | 145 |
| 70 | SW-1313 | 354/0.5 | 1.4 | 14.3 | 0.272 | 215 |
| 95 | SW-1314 | 484/0.5 | 1.6 | 16.3 | 0.206 | 260 |
| 120 | SW-1315 | 608/0.5 | 1.6 | 18 | 0.161 | 305 |
Notes
- Standard Length: 100Mtrs./300 Meters in Polybags.
Types
SAFE HOME – LF-FR :-
PVC Insulated Unsheathed Multistrand Industrial Cable With Flame Retardant Properties Confirming To: 694/2010 & 1100 Volts.
SAFE FIRE – HR-FRLSH :-
PVC Insulated Unsheathed Multistrand Industrial Cable With Heat Resistant, Flame Retardant, Low Smoke & Low Halogen Properties Confirming To: 694/2010 & 1100 Volts.
SAFE LIFE – ZHFR :-
Unsheathed Multistrand Industrial Cable Insulated With Zero Halogen Flame Retardant Compound For 1100 Volts.
Common Applications
- Electrical
- Telecom
- Electronic
- Defense & Aviation
- Computers
- Real Estate
- Railways
- IT/Networking
- Automation system
- Automobiles
- Electric Vehicle
- Charging Stations
Features
- Manufactured using 99.9% Pure Electrolytic Grade Copper having more than 100% conductivity to ensure minimum power losses and maximum safety.
- Double Insulation with virgin PVC Compound coated with ultra thin color layer having Flame Retardant & Lead Free Properties for high oxygen properties and Temperature Index.
- Bunching of Copper in uniform lay and diameter makes it energy efficient Cables.>
- ISI marked wires meet the latest requirements of IS: 694-2010 of Lead Free Flame Retardant properties ensuring extra protection against electric shocks, short circuits and fires.
