CRMA4S012DYL

Relay with Base 4CO 12VDC 5A LED

Connectwell CRM Series Modular Relay with Base 4 Changeover, Input Voltage : 12 V DC, Contact Current Rating :5 AMPS, LED Switching Power 1250 VA /150 W.
Enquire on WhatsApp
Categories: , ,

Description

Coil Data

Product Type Relay Module
Test Button No
Status Indication Red LED
Input Voltage Type DC
Input Voltage 12 V
Maximum Coil Resistance 180 Ω
Must Operate Voltage 9 V
Must Release Voltage 1.2 V
Maximum Voltage 13.2 V
Coil Power 0.9 W

Contact Data

Nominal Switching Voltage (AC) 250 VAC
Nominal Switching Voltage (DC) 30 VDC
Switching Power AC 1250 VA
Switching Power DC 150 W
Maximum Contact Resistance ≤ 50 mΩ
Contact Material Ag Alloy
Minimum Switching Current 10 mA

Electrical Data

Mechanical Life 2 × 10⁷ Operations
Electrical Life 4 × 10⁵ Operations
Switching Frequency (No Load) 18000 Operations/Hour
Switching Frequency (Full Load) 1800 Operations/Hour
Operate Time ≤ 20 ms
Release Time ≤ 20 ms
Dielectric Strength (Open Contact) 1000 V
Dielectric Strength (Coil to Contact) 2000 V
Dielectric Strength (Between Poles) 2000 V
Standard IEC 61810-1
Minimum Insulation Resistance 500 Ω

Environmental Data

Storage Temperature -55 to +80 °C
Operating Temperature -55 to +70 °C
Air Pressure 86 to 106 kPa
Shock Resistance Stability: 10G, Destructiveness: 100G
Vibration Resistance 10–55 Hz, Double Amplitude: 1.5 mm
Overvoltage Category III
Pollution Degree 3
Housing Material Polyamide
Degree of Protection IP20

Connection Data

Connection Type Screw Clamp
Conductor Cross Section (Min.) 0.2 mm²
Conductor Cross Section (Max.) 6 mm²
Conductor Size (Min.) 24 AWG
Conductor Size (Max.) 10 AWG
Wire Stripping Length 8 mm
Tightening Torque (IEC) 0.4 Nm
Tightening Torque (UL/CSA) 4.5 lb-in
