CRMA2S110DYL

Relay with Base 2CO 110VDC 5A

Connectwell CRM Series Modular Miniature Relay with Base 2 Changeover, Input Voltage : 110 V DC, Contact Current Rating :5 AMPS, Switching Power 1250 VA / 150 W.
Enquire on WhatsApp
Categories: , ,

Description

Coil Data

Product Type Relay Module
Test Button No
Status Indication No
Input Voltage Type DC
Input Voltage 110 V
Maximum Coil Resistance 22800 Ω
Must Operate Voltage 82.5 V
Must Release Voltage 11 V
Maximum Voltage 121 V
Coil Power 0.53 W

Contact Data

Nominal Switching Voltage (AC) 250 VAC
Nominal Switching Voltage (DC) 30 VDC
Switching Power AC 1250 VA
Switching Power DC 150 W
Maximum Contact Resistance ≤ 50 mΩ
Contact Material Ag Alloy
Minimum Switching Current 10 mA

Electrical Data

Mechanical Life 1 × 10⁷ Operations
Electrical Life 1 × 10⁵ Operations
Switching Frequency (No Load) 18000 Operations/Hour
Switching Frequency (Full Load) 1800 Operations/Hour
Operate Time ≤ 20 ms
Release Time ≤ 10 ms
Dielectric Strength (Open Contact) 1000 V
Dielectric Strength (Coil to Contact) 5000 V
Dielectric Strength (Between Poles) 1000 V
Standard IEC 61810-1
Minimum Insulation Resistance 1000 Ω

Environmental Data

Storage Temperature -55 to +80 °C
Operating Temperature -40 to +65 °C
Air Pressure 86 to 106 kPa
Shock Resistance Stability: 10G, Destructiveness: 100G
Vibration Resistance 10–55 Hz, Double Amplitude: 1.5 mm
Overvoltage Category III
Pollution Degree 3
Housing Material Polyamide
Degree of Protection IP20

Connection Data

Connection Type Screw Clamp
Conductor Cross Section (Min.) 0.2 mm²
Conductor Cross Section (Max.) 6 mm²
Conductor Size (Min.) 24 AWG
Conductor Size (Max.) 10 AWG
Wire Stripping Length 8 mm
Tightening Torque (IEC) 0.4 Nm
Tightening Torque (UL/CSA) 4.5 lb-in
